HARTING RJ Industrial® 10G RJ45 connector

Category: Connector Series: HARTING RJ Industrial® Element: Cable connector Specification: Straight Termination method: IDC termination Shielding: Fully shielded, 360° shielding contact Number of contacts: 8 Conductor cross-section: AWG 22 ... AWG 27 solid and stranded Wire outer diameter: =1.6 mm Limiting temperature: -40 ... +70 °C Mating cycles: = 750 Degree of protection acc. to IEC 60529: IP20 Cable diameter: 4.5 ... 9 mm Transmission characteristics: Cat. 6A Class EA up to 500 MHz Data rate: 10 Gbit/s, 10 Mbit/s, 100 Mbit/s, 2,5 Gbit/s, 5 Gbit/s, 1 Gbit/s Material (hood/housing): Polyamide Colour (hood/housing): bBack Material flammability class acc. to UL 94: V-0 Specifications: IEC 60603-7 Mating face, EN 50173-1, IEC 11801 UL / CSA: UL 1977 ECBT2.E102079, CSA-C22.2 No. 182.3 ECBT8.E102079
